The ALEX® 90-Degree Curved EMT Connector is a high-performance galvanized steel fitting designed to connect Electrical Metallic Tubing (EMT) to junction boxes or enclosures at a precise right angle.
Engineered for confined spaces where field-bending conduit is difficult or impossible, this connector features a compression mechanism that ensures a concrete-tight and vibration-resistant seal.It provides smooth wire pulling capability and reliable ground continuity, making it an essential component for commercial and industrial electrical rough-ins.
Key Features & Benefits
Space-Saving Design: Eliminates the need for large-radius field bends, allowing conduit installation in tight corners and close to walls.
Secure Compression Fit: The internal compression ring creates a firm, slip-proof grip on the conduit, ensuring mechanical safety and electrical grounding.
Wire Protection: Features a smooth, precision-machined interior surface to prevent abrasion or snagging of wire insulation during pulling.
Corrosion Resistance: Manufactured from high-strength galvanized steel to resist rust and moisture ingress in harsh environments.
Technical Specifications & Size Chart
Metric Size (mm)
Material
Angle
Connection Type
20 mm
Galvanized Steel
90°
Compression / Threaded Hub
25 mm
Galvanized Steel
90°
Compression / Threaded Hub
32 mm
Galvanized Steel
90°
Compression / Threaded Hub
40 mm
Galvanized Steel
90°
Compression / Threaded Hub
50 mm
Galvanized Steel
90°
Compression / Threaded Hub
63 mm
Galvanized Steel
90°
Compression / Threaded Hub
75 mm
Galvanized Steel
90°
Compression / Threaded Hub
Applications
Confined Spaces: Ideal for routing wiring into motors, transformers, or panels located in corners or tight clearance areas.
Retrofitting: Simplifies additions to existing conduit runs where bending tools cannot be used.
Industrial Environments: Provides a robust seal against dust and debris in manufacturing facilities.
Frequently Asked Questions (FAQ)
Q: Why use a 90-degree connector instead of bending the pipe?
A: Bending EMT requires space and specialized tools. The ALEX® 90-Degree Connector saves time and labor by providing an instant, perfect right-angle turn, which is particularly useful in tight cabinets or when routing conduit flush against a corner.
Q: Does this connector provide a waterproof seal?
A: The compression design offers a tight seal against dust, concrete slurry, and splashing water. However, for fully submersible or liquid-tight applications (like outdoor HVAC), we recommend using our Liquid Tight Flexible Conduit connectors.
Q: Is the locknut included?
A: Yes. Every 90-degree connector comes pre-assembled with a heavy-duty steel locknut to secure the threaded hub to the electrical box.
Q: Do you offer OEM branding?
A: Yes. We support OEM production. We can customize packaging and labeling to match your brand requirements for distribution.
Q: What is the lead time?
A: Our standard lead time is approximately 4 weeks. We recommend confirming specific delivery schedules with our sales team before placing large orders.
